Aluminium profile slot 8 | 11x20 - Flat - BSB
SKU BT-010101.08.00.300
Profile system: BSB
Slot type: 8
This aluminium BSB construction profile with 1 slot 8mm wide is fully compatible with the Bosch Rexroth 30 series aluminium profiles. With this profile, it is possible to easily realize structures. Thanks to the mounting slot in the extruded profile, it is possible to quickly make a connection without machining.
€5.07
€6.13
Tip:
(calculated in the checkout)
More Information
| Profile system | BSB |
|---|---|
| Slot type | 8 |
| Material | Aluminium |
| Standard length [mm] | 2060 |
| Width [mm] | 11 |
| Height [mm] | 20 |
| Finish | Anodized |
| Color | Natural |
| HS-code | 7604.29.90.90 |
| Core Count | 0 |
Technical Information
| Alloy | EN AW 6060 - T6 |
|---|---|
| Layer thickness [μm] | ± 10 |
| Profile surface [cm²] | 1.00 |
| Moment of inertia Ix [cm⁴] | 0.50 |
| Moment of inertia Iy [cm⁴] | 0.10 |
| Section modulus Wx [cm³] | 0.70 |
| Section modulus Wy [cm³] | 0.30 |
| Torsion index It [cm⁴] | 0.02 |
| Weight [kg/m] | 0.30 |
Description
This aluminium BSB construction profile with 1 slot 8mm wide is fully compatible with the Bosch Rexroth 30 series aluminium profiles. With this profile, it is possible to easily realize structures. Thanks to the mounting slot in the extruded profile, it is possible to quickly make a connection without machining.
